Sensor Tape
About FUTAI
Futai Industrial Co.,Ltd is located in Ningbo China,set up in 2010,specialized in design,manufacturing,sales and service of high-end motors and security units for doors and gates.Products including tubular motors,rubber safety edges,related electronic controllers and accessories etc.(Here in this catalogue only show rubber safety edges,other products please contact us at info@futaimotor.com).Futai persists”quality first,clients first”as company spirit...
Combination of general view
Micro sensor tape series working principle:Miniature sensor tape is composed of two conductive adhesive composite copper wire that can be divided upper and lower two parts,by a specific distance,sensing end of tape according to its different usage to connecting different plug_in units.Then insert it into rubber coating and connected to the switch,all components will form a completes system.
Integrated safety edge
EPDM Rubber Profile
Customized product
Accessories
Safety Edge is mainly used for protecting crushing and shearing points on electric shutters,sliding gates,industrial doors,automatic production lines,buses,road barriers,AGV,security and public transportations etc.According to the construction,it is divided into two types,integrated type and separated type.
1.Separated type composed by:sensitive tape,rubber profile,end piece,side plug and aluminum track;
2.Integrated type composed by:integrated sensitive edge,end piece,side plug and aluminum track.
Applications & Installations
Installation on auto production equipments,subway auto door,adjustable bed,Automatic weeding machine,Automatic lifting platform,Robot arm...
Roller shutter and doors
Bus,coach and car
Sliding gate
Revolving door
AGV,automated guided vehicle
Automatic adjustable bed
Working theory
Safety edge is made of conductive compound copper wires of upper and lower two parts.They separate at a certain distance when not squeezed.
Tehe two parts connect with end pieces and sensor processor in a series,when the safety edge be squeezed,the two parts of upper and lower contact,which lead a circuit cycle,the resistance and current change,the sensor processor received this detect this change and pass signal to the controllers,The controllers will achieve the settled functions suc as:
1)door or windows stop immediately
2)run back till upper limit
3)run back for settled seconds before stop.
